Dust Sentry PM2.5 Dust Monitor

Dust Sentry PM2.5 Dust Monitor

The Dust Sentry PM2.5 Dust Monitor provides continuous real-time monitoring of PM2.5, producing accurate, defensible data, accessible anywhere. Suitable for use on a range of projects, including urban air quality networks, industrial fenceline monitoring (especially from combustion sources), and environmental impact assessments.

Continuous real-time measurement of particulate matter (PM2.5) – accessible via any wireless device

Robust, weather-proof enclosure, suitable for use in most conditions

Can be configured to measure PM10, PM1 or TSP

Product Overview

The Dust Sentry is a modular air quality monitoring instrument for the measurement and compliance of specific dust and particulate designation. The Dust Sentry PM2.5 Dust Monitor uses a well proven near forward light scattering nephelometer and high precision sharp cut cyclone to provide continuous real-time measurement of only the PM2.5 size fraction.

Packaged in a robust weather-proof, lockable enclosure, the Dust Sentry is light enough for one-person site installations. The instrument includes an embedded PC, up to 20 years of on-board data storage, and a powerful air quality monitoring software.

What can it measure?

The Dust Sentry PM2.5 Dust Monitor provides real-time particulate measurement of PM2.5, with a measurement range of 0-60,000 μg/m3. By changing the sharp cut cyclone, the Dust Sentry PM2.5 can be configured to measure PM10, PM1 or TSP. For simultaneous measurements please see the Dust Sentry.

Options to integrate environmental sensors, such as wind, noise, weather, and solar radiation make this a complete air monitoring solution for your project.

Key Benefits of Aeroqual Products

Key Benefits of Aeroqual Products
Industry-leading sensor technology

As sensor manufacturers, we know sensors inside and out and have unparalleled expertise in optimizing performance in real-world conditions.

Protect health and safety of workers with real time industrial hygiene air monitoring
Powerful software platform

Leveraging deep integration with our monitoring systems, we deliver software functionality unmatched by off the shelf data acquisition systems.

Key Benefits of Aeroqual Products
Value-adding services

Using proprietary system diagnostics, we enable proactive maintenance with hassle-free services that virtually eliminate system downtime.

Who is it for?

Industrial operators, regulatory authorities, Environmental Health and Safety (EHS) managers, and researchers use the Aeroqual Dust Sentry PM2.5 Monitor as a cost-effective, robust solution to show particulate levels generated by site activities (particularly those involving combustion sources) are within regulatory or permitted limits and to ensure sensitive receptors, such as workers and the surrounding community, are not at risk from airborne dust and particulate matter pollution.

Practical applications for the Aeroqual Dust Sentry PM2.5 Monitor include:

  • Urban air quality networks

  • Industrial fenceline monitoring (esp. from combustion sources)

  • Roadside air monitoring

  • Environmental impact assessments

  • Research and air quality studies

Working with your sector

air-quality-monitoring-on-remediation-sites

Construction

Reduce risk and enhance your reputation by investing in a real-time construction site dust monitoring system.

Read more
Construction-Site-Dust-Monitoring

Remediation

Exceed environmental and human health standards by investing in a premium all-in-one air monitoring system.

Read more
Protect and reassure workers with hyper-local data from a real-time wildfire smoke monitor.

Wildfire Smoke Protection

Protect and reassure workers with hyper-local data from a real-time wildfire smoke monitor.

Read more
Aeroqual Ranger Portable Air Monitor

Industrial Hygiene

Maximize the health and productivity of your workforce with a real-time industrial hygiene air monitoring system from Aeroqual.

Read more

Related Products

Our Customers
  • Aeroqual
  • Aeroqual
  • Aeroqual
  • Aeroqual
  • Aeroqual

Optional Accessories

Common Questions

Before you talk to us have a look at some common questions that customers ask.

No. However, some of our distributors offer rental packages. If you’d like us to put you in touch with a local distributor who offers rental equipment, please contact us.

No. The Dust Sentry only measures dust and particulate matter.

For BTEX see our Real-Time BTEX / Benzene Monitor.

No. However, the AQS Air Quality Station is configured to measure gases and particulate matter at the same time.

No. However, the enclosure is a lockable IP65 glass-reinforced plastic (GRP) cabinet with integrated aluminium solar shield armour.

What is the environmental operating range for the Dust Sentry?

The Dust Sentry is designed to operate in environments from -10°C to +50°C (14 °F to 122 °F)

The Dust Sentry Pro is designed to operate in environments from -10 °C to +45 °C (14 °F to 113 °F)

Is the data gathered in real time?

Yes, measurements are logged and reported in real time.

What maintenance does the Dust Sentry require?

The Dust Sentry requires relatively low service and maintenance. Average service checks and filter replacements are recommended every three months. Factory calibration of the optical module is recommended annually. The optical module is easily removed and can be shipped to Aeroqual by small parcel courier service. The turnaround is approximately four weeks. For large networks which are required to operate 24/7 all year round we suggest maintaining one or more spare optical modules for exchange in instruments as service is required. Pumps are long-life high quality BLDC diaphragm type by KNF with lifetime 1-3 years. Pumps are easily replaced by the end user.

Here's what we recommend for maintenance of your Dust Sentry. View full details in the Dust Sentry User Guide.

Does the Dust Sentry have a datalogger?

Yes. It has 32GB Hard Drive (>5 years data storage).

What is the file type when you send out your data from the equipment?

File types can be CSV or FTP.

See the Aeroqual Cloud Infographic to see further details of how it works.

Is it compliant with U.S. EPA standard?

Aeroqual Dust Monitors are not U.S. EPA approved instruments but it is a near reference particle monitor for specific dust fractions.

Can the Dust Sentry be connected in the ethernet, so we can remotely access it?

Yes. You have three options to connect to the device:

  • Standard: WIFI

  • Ethernet (LAN)

Optional: Cellular IP HSPA 4G modem.

Can you integrate a third-party weather station in the Dust Sentry?

Yes, a power and data interface for designated third party sensors is included.

Here is a list of the environmental sensors that integrate with the Dust Sentry system:

  • Gill WindSonic (ultrasonic wind sensor)

  • Vaisala WXT536 (weather transmitter)

  • Met One MSO (weather transmitter)

  • Cirrus MK427 Class 1 (noise sensor)

  • Novalynx Pyranometer (solar radiation)

For more details click on the Accessories tab on the Dust Sentry product page.

How do I install the Dust Sentry? What do I need to have for installation?

The instrument is packaged in a robust, lockable enclosure and is light enough for one-person site installations.

See the Dust Sentry User Guide on for full details on how to install the unit.

Is the sensor calibrated when we receive it? How do I calibrate the sensor?

Yes, it is already factory calibrated. All Aeroqual PM engines need to be returned to the Met One Instruments factory in the U.S for service and calibration at the following recommended intervals:

  1. Dust Sentry Particle Monitor: 24 Months

  2. Dust Sentry Pro Particle Profiler: 12 Months

Aeroqual can arrange for this service. Contact support@aeroqual.com for further details.

Can it run through solar or battery?

Yes. To read more, see this technical note on How to remote/solar power the Dust Monitor.

Does it have self-diagnostic and self-correct function?

No. However, it has alerts to notify you that there is an error that needs attention. Those alerts can be set by the end user.

Does the Dust Sentry have a weatherproof enclosure?

Yes, the enclosure is a lockable IP65 glass-reinforced plastic (GRP) cabinet with integrated aluminium solar shield armour.

What is the dimension and weight of a Dust Sentry?

483 H x 330 W x 187 D mm (19 H x 13 W x 7.4 D inches) includes solar shield armour and mounting brackets and it weighs <13 kg (28.6 lbs).

Does the Dust Sentry have any certifications?

Yes. Dust Sentry PM10 is MCERTS certified by UK Environment Agency and Pre-approved for Rule 1466 compliance by SCAQMD, USA.
